Single Block & Bleed Built to Isolate.
Three connection families — Monoflange, Flange-to-Pipe, and threaded Block & Bleed — covering primary instrument isolation and bleed. SS316 construction, Class 150 to 1500 and PN16, with NACE MR-0175 and Fire Safe options. Pressure rating depends on configuration — contact us to confirm.
1500
Max pressure class
3
Connection families
SS316
Construction
Class 1500
Maximum pressure class
One block. One bleed.
PANAM® Single Block & Bleed valves cover primary instrument isolation and bleed — Monoflange (all-screwed-bonnet), Flange-to-Pipe, and compact threaded Block & Bleed configurations. All three families share SS316 construction with isolation plus an integral bleed/vent for safe venting before instrument removal.
SBB options include NACE MR-0175, Fire Safe, and Locking Handle. Seat and seal/packing materials cover PTFE, PEEK, and Grafoil.
Technical Specifications
Connection Types
Monoflange · Flange-to-Pipe · Block & Bleed
Construction
Screwed Bonnet · Integral · Bar Stock
Pressure Classes
Class 150 – 1500 · PN16 · rating depends on configuration
Flange Faces
RF (flanged families)
Material
Stainless Steel 316
Configurations
Block & Bleed · Isolate & Drain · Ball-Needle
Seat Materials
PTFE · PEEK
Seal / Packing
PTFE · Grafoil
Special Service
NACE MR-0175 option · Fire Safe option · Locking Handle
Three Families. One Standard.
Each SBB family is purpose-built for a specific connection type and application. Select by connection style, pressure class, or special service requirement.
PANAM® SBB Valves
SBB — Monoflange (Screwed Bonnet)
Single Block & Bleed monoflange valves with all-screwed-bonnet construction for primary instrument isolation and drain. Flange-mounted directly to the process with a threaded outlet to the instrument and an integral bleed/vent. SS316 with PTFE packing, Class 150 to 1500 and PN16, RF flange faces. NACE MR-0175 option available.
SS316 · PTFE Packing · NACE Option
PANAM® SBB Valves
SBB — Flange to Pipe
Single Block & Bleed valves with Flange-to-Pipe integral construction in a Ball-Needle arrangement for primary isolation and bleed. SS316 body with PEEK seats and Grafoil seals, Class 150 RF flanged inlet with a threaded NPT outlet and vent. Fire Safe, Anti-Static, and Locking Handle options.
SS316 · PEEK Seat · Grafoil Seal
PANAM® SBB Valves
SBB — Block & Bleed (Threaded)
Compact threaded Block & Bleed valves for isolation and bleed on instrument lines. SS316 body and trim with PEEK seats and Grafoil seals, BSPP female inlet, outlet, and vent (vent supplied with plug). Fire Safe and Locking Handle options available.
SS316 Body & Trim · PEEK / Grafoil
Which SBB Valve Do You Need?
Start from the connection your installation requires — each connection style maps to one PANAM® Single Block & Bleed family. Use this to shortlist before requesting a quote.
Your installation
SBB family
Pressure class
Ends / faces
Flange-mounted primary isolation & drain
Monoflange (Screwed Bonnet) · Class 150 – 1500 · PN16 · RF Flange
Monoflange (Screwed Bonnet)
Class 150 – 1500 · PN16
RF Flange
Flange to pipe — isolation & bleed with ball-needle
Flange to Pipe · Class 150 · RF / 10mm bore
Flange to Pipe
Class 150
RF / 10mm bore
Threaded block & bleed on instrument lines
Block & Bleed (Threaded) · On request · BSPP / 12mm bore
Block & Bleed (Threaded)
On request
BSPP / 12mm bore
Sour Service & Fire Safe
What to consider
Where this range is used
Sour service (NACE MR-0175)
NACE MR-0175 governs material selection for equipment exposed to H2S-containing (sour) environments, requiring controlled hardness and resistance to sulfide stress cracking. A NACE MR-0175 option is available on PANAM® Single Block & Bleed valves — tell us at enquiry and we will confirm the configuration.
Fire safe service
A Fire Safe option is available on the ported SBB families (Flange-to-Pipe and Block & Bleed), alongside a choice of seat (PTFE, PEEK) and seal (PTFE, Grafoil) materials. Share your media, pressure class and service at enquiry and we will confirm the right build.
Why specify PANAM® SBB Valves
All three SBB families are built to the same engineering standard — consistent materials, construction, and test procedures across the entire range.
Three SBB families from a single trusted manufacturer
Stainless Steel 316 construction across all series
Monoflange, Flange-to-Pipe, and threaded Block & Bleed connection styles
Class 150 to 1500 and PN16 pressure classes on the flanged families
NACE MR-0175 option available
Block & Bleed, Isolate & Drain, and Ball-Needle configurations
All-screwed-bonnet monoflange for serviceable primary isolation
PTFE and PEEK seat materials
PTFE and Grafoil seal / packing materials
Fire Safe option on the ported families
Locking Handle and Anti-Static options
RF flanged and BSPP / NPT threaded end connections
Talk to our team
Specify your SBB valve
Send us your connection type, pressure class, inlet size, and any special service requirements. Our technical team responds to instrumentation enquiries within 24 hours.
Reply within 24 hours
