COMPREHENSIVE SOLUTIONS
Engineered Integrity Across Applications.
Explore our full range of high-performance instrumentation valves and fittings. Designed for absolute integrity, Panam components are the backbone of critical flow control systems worldwide.
Engineered Integrity
Product Catalog.
Our comprehensive catalog defines the industry standard for leak-free performance. Explore technical specifications for high-pressure instrumentation components built for the world's most demanding fluid systems.
High Pressure Fittings & Valves
Hydrogen-ready fittings, needle valves, ball valves and double block & bleed assemblies rated to 60,000 psi for high-pressure and hydrogen fuel infrastructure.
Featured Specs
High Pressure FittingsHigh Pressure Pipe FittingsHigh Pressure Needle ValvesHigh Pressure Ball ValvesHigh Pressure DBB
View Category
Instrumentation Fittings
Tube, JIC, pipe and weld fittings in stainless steel for leak-tight instrumentation and process connections across oil & gas, chemical and industrial systems.
Featured Specs
View Category
Filters
In-line and T-type instrumentation filters protecting gas and liquid lines from particulate contamination.
Featured Specs
View Category
Quick Coupling & Tubing
Quick-connect couplings and precision tubing for fast, secure fluid and gas line connections in industrial and instrumentation applications.
View Category
Valves
Needle, ball, check and relief valves in SS316, Duplex and exotic alloys for isolation, throttling and overpressure protection across critical flow control systems.
Featured Specs
View Category
Manifolds
2-, 3- and 5-valve instrument manifolds in 6K and 10K pressure classes for transmitter isolation, calibration and venting.
Featured Specs
View Category
Double Block and Bleed
DBB valve assemblies in flange-to-flange, flange-to-pipe and pipe-to-pipe configurations for safe double isolation and pressure bleed-off.
Featured Specs
View Category
Single Block and Bleed
Single Block & Bleed valves in monoflange, flange-to-pipe and threaded block & bleed configurations for primary instrument isolation and bleed.
Featured Specs
View Category
Tubing
Stainless steel instrumentation tubing rated for high-pressure gas and liquid service, compatible with our full tube fitting range.
Featured Specs
View Category
Regulators & Transmitter
Pressure transmitters and regulation solutions for accurate process monitoring and control in demanding industrial environments.
View Category
System Integration
Grab sampling systems, air headers, condensate pots and flange adaptors engineered for turnkey instrumentation skid integration.
Featured Specs
View Category
Technical CatalogHigh Pressure Fluid ControlInstrumentation Standards
Technical Reference
Pressure Classes, Seat Materials & Metallurgy
Every product in this catalog is specified against a known pressure class, seat material and body metallurgy — the same reference our technical team uses when matching a component to your application.
Pressure Classes
Working pressure ranges across our standard and high-pressure ranges — the starting point for matching a component to your process conditions.
| # | Series | Scope |
|---|---|---|
| 01 | 6K / 10K / 15K / 20K psig 20,000 psi | SS316 across ball, needle, manifolds and DBB — standard instrumentation classes |
| 02 | MP Cone & Thread — 20,000 psi 20,000 psi | Compact, weld-free sealing for very high pressure or tight envelopes |
| 03 | HP Cone & Thread — 60,000 psi 60,000 psi | Proven for hydrogen and offshore service; HP needle valves extend to this class |
| # | Material | Notes |
|---|---|---|
| 01 | PTFE | Broad chemical resistance, typical to ~200°C. Standard for many ball seats and needle packing. |
| 02 | PEEK | Higher temperature and deformation resistance; suited to higher delta-P and compressible gas service. |
| 03 | KEL-F (PCTFE) | Cryogenic and low-temperature service with good permeation resistance. |
| 04 | Graphoil | High-temperature packing to 538°C in needle and manifold bonnets. |
| # | Material | Application |
|---|---|---|
| 01 | SS316 | Standard choice for most utilities and clean process streams |
| 02 | Duplex | Higher strength and chloride stress corrosion resistance; common offshore |
| 03 | Monel | Excellent seawater and hydrofluoric acid resistance |
| 04 | Hastelloy | Aggressive chemical resistance in refining and chemical plants |
CATALOG FAQ
Frequently Asked Questions
Can't find what you're looking for? Ask our technical team.
Yes. Most valve, manifold and fitting ranges support our online Product Configurator — choose end connections, materials, pressure ratings and certifications, then add your exact build straight to an order.
Lead times vary by product, material, documentation requirements and order volume, and are confirmed at quotation.
Our quality management system is certified to ISO 9001:2015, ISO 14001:2015 and ISO 45001:2018. We also hold ATEX and PED documents, which you can view on our certificates page. Material certificates are available on request.
Yes — apply for a trade credit account to streamline repeat ordering and invoicing. You can start an application any time from the 'Apply for Credit' link in the site header.
Every order includes access to full technical documentation: our Catalog Library, 2D/3D drawings and CAD files ready for direct import into your design workflow.
